Din 1.4305 301 Stainless Steel Coil 20-610mm 201 304 316 409 201 304

Place of Origin CHINA
Brand Name TISCO, ZPSS, BAOSTEEL, POSCO, JISCO, LISCO, etc
Certification mill certificate
Model Number 304L hot rolled/cold rolled stainless steel coil
Minimum Order Quantity 25T
Price negothiable
Packaging Details Export Package
Delivery Time 15-20 days after deposit
Payment Terms L/C, T/T
Supply Ability 2000T PER MONTH OR MORE

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material 304L Hot Rolled/cold Rolled Stainless Steel Coil Standard JIS, AiSi, ASTM, GB, DIN, EN
Type Coil Thickness 0.3-6mm
Width 20-610mm Technique Hot Rolled
Surface Treatment Polished Grade 300 Series
Processing Service Bending, Welding, Cutting Surface Finish BA, BA
Application Construction Steel Grade 316, 321, 304
Length 6-12m
High Light

301 stainless steel coil 20mm

,

301 stainless steel coil 610mm

,

hot rolled 316l coil

Leave a Message
Product Description

304L hot rolled/cold rolled stainless steel coil



304L is the low carbon version of 304. It is used in heavy gauge components for improved weldability. 304L has a carbon maximum is 0.030. Austenitic Cr-Ni stainless steel. Better corrosion resistance than 302. High ductility, excellent drawing, forming, and spinning properties. Essentially non-magnetic, becomes slightly magnetic when cold worked. Low carbon content means less carbide precipitation in the heat-affected zone during welding and a lower susceptibility to intergranular corrosion. Applications include beer barrels, bellows, chemical equipment, coal hopper linings, cooling coils, cryogenic vessels, dairy equipment, evaporators, feedwater tubing, flexible metal hose, food processing equipment, hypodermic needles, nuclear vessels, oil well filter screens, refrigeration equipment, paper industry, pressure vessels, sanitary fittings, valves, shipping drums, spinning, still tubes, textile dyeing equipment, tubing.

ElementType 304L (Wt.%)

Carbon: 0.03 max

Manganese: 2.00 max.

Phosphorus: 0.045 max.

Sulfur: 0.030 max.

Silicon: 1.00 max.

Chromium: 18.00-20.00

Nickel: 9.00-12.00



Element (Wt.%)

Carbon Manganese Phosphorus Sulfur Silicon Chromium Nickel
0.03max 2.00max 0.045max 0.030max 1.00max 18.00-20.00 9.00-12.00





Mechanical Property

Material Item Tensile Strength (MPa) Yield Strength (MPa) Extension Hardness (HV) Density
304L ≥480 ≥175 ≥40% ≤200 7.93g/cm³





Surface Treatment

Surface Treatment Definition Application
NO.1 A hot - rolled piece whose surface has been treated by heat treatment, pickling or the corresponding process Chemical Tanks, Pipes, Chemical Industry Equipment etc.
2B After cold rolling, heat treatment, pickling or other equivalent treatment, the final cold rolling to give appropriate luster Medical Equipment, Food Industry, Construction Material, Kitchen Utensils etc.
BA After cold rolling, bright heat treatment is given Kitchen Utensils, Electric Equipment, Building Construction etc.
NO.4 Products polished with abrasives 150 to 180 as specified in JIS R6001 Kitchen Utensils, Building Construction, Medical Equipment etc.
HL After polishing, use the appropriate abrasive size to form a continuous polishing streak Building Construction etc.
8K A mirror-like reflective surface given by polishing with finer abrasives over 800 mesh Reflector, Mirror, Interior and exterior decoration etc.







COIL

Commodity 304L hot rolled/cold rolled stainless steel coil
Brand TISCO, ZPSS, BAOSTEEL, POSCO, JISCO, LISCO, etc
Surface No.1/ 2B/ BA/ No.4/ 8K/ HL
Thickness 0.3mm-16mm
Width 1000mm-2000mm, or as customized
Length as customized
Application beer barrels, bellows, chemical equipment, coal hopper linings, cooling coils, cryogenic vessels, dairy equipment, evaporators, feedwater tubing, flexible metal hose, food processing equipment, hypodermic needles, nuclear vessels, oil well filter screens, refrigeration equipment, paper industry, pressure vessels, sanitary fittings, valves, shipping drums, spinning, still tubes, textile dyeing equipment, tubing
Delivery Time Normally within 15 days, according to the quantity
Price Terms FOB/ CFR/ CIF
Package Standard Export Packaging

Din 1.4305 301 Stainless Steel Coil 20-610mm 201 304 316 409 201 304 0

Din 1.4305 301 Stainless Steel Coil 20-610mm 201 304 316 409 201 304 1

Din 1.4305 301 Stainless Steel Coil 20-610mm 201 304 316 409 201 304 2

Din 1.4305 301 Stainless Steel Coil 20-610mm 201 304 316 409 201 304 3

FAQ

Q1:What product information must I provide before making a purchase?

Please provide the grade, width, thickness, and surfacetreatment requirements, cold or hot ,as well as the quantities you require.
Q2:What shipping ports are there?
We normally ship from Shanghai,which is very near to my company , if you have other ports requirement, you could tell us in advance
Q3:What are your payment terms?
30% T/T in advance and 70% balance before shipment or LC at sight.
Q4:What about product pricing information?
Prices vary due to changes in raw material prices on a regular basis.
Q5:Is it possible to send samples?
Of course, we offer free samples and express shipping to customers all over the world.
Q6:Do you offer a service for customized products?
Yes, we can produce according to your specifications and drawings.
Q7:Can I pay you a visit at your factory?
Customers from all around the world are welcome to visit our factory.
Q8:Can you assist me in importing steel products for the first time?
Yes, we have shipping agent who will arrange the shipment with you.
