Din 1.4305 301 Stainless Steel Coil 20-610mm 201 304 316 409 201 304
Place of Origin | CHINA |
---|---|
Brand Name | TISCO, ZPSS, BAOSTEEL, POSCO, JISCO, LISCO, etc |
Certification | mill certificate |
Model Number | 304L hot rolled/cold rolled stainless steel coil |
Minimum Order Quantity | 25T |
Price | negothiable |
Packaging Details | Export Package |
Delivery Time | 15-20 days after deposit |
Payment Terms | L/C, T/T |
Supply Ability | 2000T PER MONTH OR MORE |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xMaterial | 304L Hot Rolled/cold Rolled Stainless Steel Coil | Standard | JIS, AiSi, ASTM, GB, DIN, EN |
---|---|---|---|
Type | Coil | Thickness | 0.3-6mm |
Width | 20-610mm | Technique | Hot Rolled |
Surface Treatment | Polished | Grade | 300 Series |
Processing Service | Bending, Welding, Cutting | Surface Finish | BA, BA |
Application | Construction | Steel Grade | 316, 321, 304 |
Length | 6-12m | ||
High Light | 301 stainless steel coil 20mm,301 stainless steel coil 610mm,hot rolled 316l coil |
304L hot rolled/cold rolled stainless steel coil
304L is the low carbon version of 304. It is used in heavy gauge components for improved weldability. 304L has a carbon maximum is 0.030. Austenitic Cr-Ni stainless steel. Better corrosion resistance than 302. High ductility, excellent drawing, forming, and spinning properties. Essentially non-magnetic, becomes slightly magnetic when cold worked. Low carbon content means less carbide precipitation in the heat-affected zone during welding and a lower susceptibility to intergranular corrosion. Applications include beer barrels, bellows, chemical equipment, coal hopper linings, cooling coils, cryogenic vessels, dairy equipment, evaporators, feedwater tubing, flexible metal hose, food processing equipment, hypodermic needles, nuclear vessels, oil well filter screens, refrigeration equipment, paper industry, pressure vessels, sanitary fittings, valves, shipping drums, spinning, still tubes, textile dyeing equipment, tubing.
ElementType 304L (Wt.%)
Carbon: 0.03 max
Manganese: 2.00 max.
Phosphorus: 0.045 max.
Sulfur: 0.030 max.
Silicon: 1.00 max.
Chromium: 18.00-20.00
Nickel: 9.00-12.00
Element (Wt.%)
Carbon | Manganese | Phosphorus | Sulfur | Silicon | Chromium | Nickel |
0.03max | 2.00max | 0.045max | 0.030max | 1.00max | 18.00-20.00 | 9.00-12.00 |
Mechanical Property
Material Item | Tensile Strength (MPa) | Yield Strength (MPa) | Extension | Hardness (HV) | Density |
304L | ≥480 | ≥175 | ≥40% | ≤200 | 7.93g/cm³ |
Surface Treatment
Surface Treatment | Definition | Application |
NO.1 | A hot - rolled piece whose surface has been treated by heat treatment, pickling or the corresponding process | Chemical Tanks, Pipes, Chemical Industry Equipment etc. |
2B | After cold rolling, heat treatment, pickling or other equivalent treatment, the final cold rolling to give appropriate luster | Medical Equipment, Food Industry, Construction Material, Kitchen Utensils etc. |
BA | After cold rolling, bright heat treatment is given | Kitchen Utensils, Electric Equipment, Building Construction etc. |
NO.4 | Products polished with abrasives 150 to 180 as specified in JIS R6001 | Kitchen Utensils, Building Construction, Medical Equipment etc. |
HL | After polishing, use the appropriate abrasive size to form a continuous polishing streak | Building Construction etc. |
8K | A mirror-like reflective surface given by polishing with finer abrasives over 800 mesh | Reflector, Mirror, Interior and exterior decoration etc. |
COIL
Commodity | 304L hot rolled/cold rolled stainless steel coil |
Brand | TISCO, ZPSS, BAOSTEEL, POSCO, JISCO, LISCO, etc |
Surface | No.1/ 2B/ BA/ No.4/ 8K/ HL |
Thickness | 0.3mm-16mm |
Width | 1000mm-2000mm, or as customized |
Length | as customized |
Application | beer barrels, bellows, chemical equipment, coal hopper linings, cooling coils, cryogenic vessels, dairy equipment, evaporators, feedwater tubing, flexible metal hose, food processing equipment, hypodermic needles, nuclear vessels, oil well filter screens, refrigeration equipment, paper industry, pressure vessels, sanitary fittings, valves, shipping drums, spinning, still tubes, textile dyeing equipment, tubing |
Delivery Time | Normally within 15 days, according to the quantity |
Price Terms | FOB/ CFR/ CIF |
Package | Standard Export Packaging |
FAQ
Q1:What product information must I provide before making a purchase?
Q6:Do you offer a service for customized products?
