ERW SAW 316 Stainless Steel Seamless Pipe 304 304l 316l 316ti 904L 2101 2205 2507
Place of Origin | CHINA |
---|---|
Brand Name | TISCO, ZPSS, BAOSTEEL, POSCO, JISCO, LISCO, etc |
Certification | mill certificate |
Model Number | 904L seamless stainless steel pipe |
Minimum Order Quantity | 25T |
Price | negothiable |
Packaging Details | Export Package |
Delivery Time | 15-20 days after deposit |
Payment Terms | L/C, T/T |
Supply Ability | 2000T PER MONTH OR MORE |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xMaterial | 904L Seamless Stainless Steel Pipe | Standard | EN, BS, JIS, Etc |
---|---|---|---|
Type | Seamless Stainless Steel Pipe | Size | 6mm - 1174mm Or Customized |
Grade | Q235, Q235B, S275, S275jr, A53, St37, Etc | Oiled Or Non-oiled | Non-oiled |
Application | Fluid Pipe, Boiler Pipe, Drill Pipe, Hydraulic Pipe, Gas Pipe, | Technique | ERW, SAW |
OD | 10mm 20mm | Length | 1000-5800mm,6000-12000mm |
Processing Service | Bending, Welding, Decoiling, Punching, Cutting, Moulding | Surface Finish | 2B |
Section Shape | Round | ||
High Light | SAW 316 Stainless Steel Seamless Pipe,ERW 316 Stainless Steel Seamless Pipe,2101 seamless stainless steel tubing |
904L seamless stainless steel pipe
904L is an austenitic stainless steel. In comparison to 316L, its molybdenum addition gives it superior resistance to localized attack (pitting and crevice corrosion) by chlorides and greater resistance reducing acids and in particular its copper addition gives it useful corrosion resistance to all concentrations of sulphuric acid. Its high alloying content also gives it greater resistance to chloride stress corrosion cracking, but it is still susceptible. Its low carbon content makes it resistant to sensitization by welding and which prevents intergranular corrosion.
It has applications in piping systems, pollution control equipment, heat exchangers, and bleaching systems.
Application
Chemical plant, oil refinery, petrochemical plants, bleaching tanks for the paper industry, combustion gas desulfurisation plants, application in sea water, sulphuric and phosphoric acid. Due to the low C-content, the resistance to intergranular corrosion is also guaranteed in the welded condition.
ElementType 904L (Wt.%)
Carbon: 0.02 max
Manganese: 2.00 max.
Phosphorus: 0.045 max.
Sulfur: 0.035 max.
Silicon: 1.00 max.
Chromium: 19.00-23.00
Nickel: 23.00-28.00
Copper: 1.00-2.00
Molybdenum: 4.00-5.00
Element (Wt.%)
Carbon | Manganese | Phosphorus | Sulfur | Silicon | Chromium | Nickel | Copper | Molybdenum |
0.02max | 2.00max | 0.045max | 0.035max | 1.00max | 19.00-23.00 | 23.00-28.00 | 1.00-2.00 | 4.00-5.00 |
Surface Treatment
Surface Treatment | Definition | Application |
NO.1 | A hot - rolled piece whose surface has been treated by heat treatment, pickling or the corresponding process | Chemical Tanks, Pipes, Chemical Industry Equipment etc. |
2B | After cold rolling, heat treatment, pickling or other equivalent treatment, the final cold rolling to give appropriate luster | Medical Equipment, Food Industry, Construction Material, Kitchen Utensils etc. |
BA | After cold rolling, bright heat treatment is given | Kitchen Utensils, Electric Equipment, Building Construction etc. |
NO.4 | Products polished with abrasives 150 to 180 as specified in JIS R6001 | Kitchen Utensils, Building Construction, Medical Equipment etc. |
HL | After polishing, use the appropriate abrasive size to form a continuous polishing streak | Building Construction etc. |
8K | A mirror-like reflective surface given by polishing with finer abrasives over 800 mesh | Reflector, Mirror, Interior and exterior decoration etc. |
Commodity | 904L seamless stainless steel pipe |
Grade | 904L |
OD | 6mm-426mm, or as customized |
WT | 1mm-30mm, or as customized |
Length | 5m-7m, or as customized |
Surface | Pickling, matt, polished, mirror |
Application | handrail, railing, staircase, weld mesh screen, door, window, balcony, fence, bench, furniture, etc. |
Delivery Time | 7-30 days, according to quantity |
Price Terms | FOB/ CFR/ CIF |
Package | In bundles, water proof packing, in wooden case, or as per customers’ requirement |
