304 Cold Rolled Stainless Steel Strip Ba Finish AISI Duplex 304 0.5mm In Coil
Place of Origin | CHINA |
---|---|
Brand Name | TISCO, ZPSS, BAOSTEEL, POSCO, JISCO, LISCO, etc |
Certification | mill certificate |
Model Number | 309S stainless steel strip |
Minimum Order Quantity | 25T |
Price | negothiable |
Packaging Details | Export Package |
Delivery Time | 15-20 days after deposit |
Payment Terms | L/C, T/T |
Supply Ability | 2000T PER MONTH OR MORE |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xMaterial | 309S Stainless Steel Strip | Standard | JIS, AiSi, ASTM, GB, DIN, EN |
---|---|---|---|
Type | Strip | Thickness | 0.02mm-5mm |
Width | 20-610mm | Length | 6-12m |
Technique | Hot Rolled | Surface Treatment | Polished |
Grade | 300 Series | Processing Service | Bending, Welding, Cutting |
Surface Finish | BA, BA | Application | Construction |
Steel Grade | 316, 321, 304 | ||
High Light | 304 cold rolled stainless steel strip,cold rolled stainless steel strip 0.5mm,ba duplex steel coil |
309S stainless steel strip
309S stainless steel is a low carbon version of 309. Because of its lower carbon-content, 309S minimizes carbide precipitation, and improves weldability. It can be easily roll formed, stamped and drawn. Other key properties of 309S include good weldability and machinability, outstanding resistance to oxidation. 309S is utilized by many different industries for a number of critical applications including:oven Linings, boiler baffles, firebox sheets, furnace components, most high temperature containers, aircraft and jet engine parts and so on.
ElementType 309S (Wt.%)
Carbon: 0.08 max
Manganese: 2.00 max.
Phosphorus: 0.045 max.
Sulfur: 0.030 max.
Silicon: 1.00 max.
Chromium: 22.00-24.00
Nickel: 12.00-15.00
Element (Wt.%)
Carbon | Manganese | phosphorus | Sulfur | Silicon | Chromium | Nickel |
0.08max | 2.00max | 0.045max | 0.030max | 1.00max | 22.00-24.00 | 12.00-15.00 |
Mechanical Property
Material Item | Tensile Strength (MPa) | Yield Strength (MPa) | Extension | Hardness (HV) | Density |
309S | ≥520 | ≥205 | ≥40% | ≤200 | 7.98g/cm³ |
Surface Treatment
Surface Treatment | Definition | Application |
NO.1 | A hot - rolled piece whose surface has been treated by heat treatment, pickling or the corresponding process | Chemical Tanks, Pipes, Chemical Industry Equipment etc. |
2B | After cold rolling, heat treatment, pickling or other equivalent treatment, the final cold rolling to give appropriate luster | Medical Equipment, Food Industry, Construction Material, Kitchen Utensils etc. |
BA | After cold rolling, bright heat treatment is given | Kitchen Utensils, Electric Equipment, Building Construction etc. |
NO.4 | Products polished with abrasives 150 to 180 as specified in JIS R6001 | Kitchen Utensils, Building Construction, Medical Equipment etc. |
HL | After polishing, use the appropriate abrasive size to form a continuous polishing streak | Building Construction etc. |
8K | A mirror-like reflective surface given by polishing with finer abrasives over 800 mesh | Reflector, Mirror, Interior and exterior decoration etc. |
STRIP
Commodity | 309S stainless steel strip |
Brand | TISCO, ZPSS, BAOSTEEL, POSCO, JISCO, LISCO, etc |
Surface | No.1/ 2B/ BA/ No.4/ 8K/ HL |
Thickness | 0.02mm-5mm |
Width | 15mm-600mm |
Length | as customized |
Application | oven Linings, boiler baffles, firebox sheets, furnace components, most high temperature containers, aircraft and jet engine parts, etc |
Delivery Time | Normally within 15 days, according to the quantity |
Price Terms | FOB/ CFR/ CIF |
Package | Standard Export Packaging |
