Hot Rolled Stainless Steel 304 Flat Bar 20mm BA Polished For Construction

Place of Origin CHINA
Brand Name TISCO, ZPSS, BAOSTEEL, POSCO, JISCO, LISCO, etc
Model Number 321 stainless steel flat bar
Minimum Order Quantity 25T
Price negothiable
Packaging Details Export Package
Delivery Time 15-20 days after deposit
Payment Terms L/C, T/T
Supply Ability 2000T PER MONTH OR MORE

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Width 20-610mm Technique Hot Rolled
Surface Treatment Polished Grade 300 Series
Processing Service Bending, Welding, Cutting Surface Finish BA, BA
Application Construction Steel Grade 316, 321, 304
Length 6-12m
High Light

hot rolled stainless steel 304 flat bar

,

20mm ss 304 flat bar

,

polished ss 304 flat bar

Leave a Message
Product Description

321 stainless steel flat bar



321 SS is a titanium stabilized austenitic chromium-nickel stainless steel which was developed to provide an 18-8 type alloy with improved intergranular-corrosion resistance. This material is stabilized against chromium carbide formation by the addition of titanium. Since titanium has a stronger affinity for carbon than chromium, titanium carbide precipitates within the grains instead of forming at the grain boundaries. 321 stainless steel should be considered for applications requiring intermittent heating between 800ºF (427ºC) and 1650ºF (899ºC), or for welding under conditions which prevent a post-weld anneal. 321 stainless steel is non-magnetic.

Typical applications include:

Aircraft exhaust manifolds, expansion joints, bellows, furnace parts, heating element tubing, heat exchangers, woven or welded screens for high-temperature mineral processing, spiral welded tube for burner pipes and flues



ElementType 321 (Wt.%)

Carbon: 0.08 max

Manganese: 2.00 max.

Phosphorus: 0.045 max.

Sulfur: 0.030 max.

Silicon: 1.00 max.

Chromium: 17.00-19.00

Nickel: 9.00-13.00

Titanium: 5(C+N) min/ 0.70 max



Element (Wt.%)

Carbon Manganese Phosphorus Sulfur Silicon Chromium Nickel Titanium
0.08max 2.00max 0.045max 0.030max 1.00max 17.00-19.00 9.00-13.00 5(C+N) min/ 0.70 max





Mechanical Property

Material Item Tensile Strength (MPa) Yield Strength (MPa) Extension Hardness (HV) Density
321 ≥520 ≥205 ≥40% ≤200 8.03g/cm³





Hot rolled

Commodity 321 hot rolled stainless steel sheet
Brand TISCO, ZPSS, BAOSTEEL, POSCO, JISCO, LISCO, etc
Thickness 3mm-30mm, or as customized
Width 1500mm/1800mm/2000mm, or as customized
Length 2000mm/2438mm/6000mm, or as customized
Application Aircraft exhaust manifolds, expansion joints, bellows, furnace parts, heating element tubing, heat exchangers, woven or welded screens for high-temperature mineral processing, spiral welded tube for burner pipes and flues, etc
Delivery Time

Within 15 days for less than 100mt

About 30 days for on and more than 100mt

Price Terms FOB/ CFR/ CIF
Package Standard Export Packaging





Cold rolled

Commodity 321 cold rolled stainless steel sheet
Brand TISCO, ZPSS, BAOSTEEL, POSCO, JISCO, LISCO, etc
Thickness 0.3mm-6mm
Width 1000mm/1220mm/1500mm/2000mm, or as customized
Length 2000mm/2438mm/6000mm, or as customized
Surface 2B/ BA/ No.4/ 8K/ HL
Application Aircraft exhaust manifolds, expansion joints, bellows, furnace parts, heating element tubing, heat exchangers, woven or welded screens for high-temperature mineral processing, spiral welded tube for burner pipes and flues, etc
Delivery Time

Within 15 days for less than 100mt

About 30 days for on and more than 100mt

Price Terms FOB/ CFR/ CIF
Package Standard Export Packaging





Surface Treatment

Surface Treatment Definition Application
NO.1 A hot - rolled piece whose surface has been treated by heat treatment, pickling or the corresponding process Chemical Tanks, Pipes, Chemical Industry Equipment etc.
2B After cold rolling, heat treatment, pickling or other equivalent treatment, the final cold rolling to give appropriate luster Medical Equipment, Food Industry, Construction Material, Kitchen Utensils etc.
BA After cold rolling, bright heat treatment is given Kitchen Utensils, Electric Equipment, Building Construction etc.
NO.4 Products polished with abrasives 150 to 180 as specified in JIS R6001 Kitchen Utensils, Building Construction, Medical Equipment etc.
HL After polishing, use the appropriate abrasive size to form a continuous polishing streak Building Construction etc.
8K A mirror-like reflective surface given by polishing with finer abrasives over 800 mesh Reflector, Mirror, Interior and exterior decoration etc.



PIPE

Commodity 321 seamless/welded stainless steel pipe
Grade 321
OD 6mm-426mm, or as customized
WT 1mm-30mm, or as customized
Length 5m-7m, or as customized
Surface Pickling, matt, polished, mirror
Application Construction field, ships building industry, petroleum & chemical industries, war and electricity industries, food processing and medical industry, boiler heat exchange, machinery hardware fields, etc.
Delivery Time 7-30 days, according to quantity
Price Terms FOB/ CFR/ CIF
Package In bundles, water proof packing, in wooden case, or as per customers’ requirement





COIL

Commodity 321 hot rolled/cold rolled stainless steel coil
Brand TISCO, ZPSS, BAOSTEEL, POSCO, JISCO, LISCO, etc
Surface No.1/ 2B/ BA/ No.4/ 8K/ HL
Thickness 0.3mm-16mm
Width 1000mm-2000mm, or as customized
Length as customized
Application Aircraft exhaust manifolds, expansion joints, bellows, furnace parts, heating element tubing, heat exchangers, woven or welded screens for high-temperature mineral processing, spiral welded tube for burner pipes and flues, etc
Delivery Time Normally within 15 days, according to the quantity
Price Terms FOB/ CFR/ CIF
Package Standard Export Packaging





Bar

Commodity 321 stainless steel round bar
Diameter 1mm-800mm
Length 6m, or as customized
Surface Bright, pickled, black
Application Construction field, shipbuilding industry, petroleum & chemical industries, war and electricity industries, food processing and medical industry, boiler heat exchange, machinery hardware fields
Delivery Time 7-30 days, according to quantity
Price Terms FOB/ CFR/ CIF
Package Export standard package, or as per customers’ requirement







STRIP

Commodity 321 stainless steel strip
Brand TISCO, ZPSS, BAOSTEEL, POSCO, JISCO, LISCO, etc
Surface No.1/ 2B/ BA/ No.4/ 8K/ HL
Thickness 0.02mm-5mm
Width 15mm-600mm
Length as customized
Application Aircraft exhaust manifolds, expansion joints, bellows, furnace parts, heating element tubing, heat exchangers, woven or welded screens for high-temperature mineral processing, spiral welded tube for burner pipes and flues, etc
Delivery Time Normally within 15 days, according to the quantity
Price Terms FOB/ CFR/ CIF
Package Standard Export Packaging





Flat Bar

Commodity 321 stainless steel flat bar
Thickness 3mm-60mm
Width 10mm-200mm, or as customized
Length 6m, or as customized
Surface Bright, pickled, black, polished
Application Construction field, shipbuilding industry, petroleum & chemical industries, war and electricity industries, food processing and medical industry, boiler heat exchange, machinery hardware fields
Delivery Time 7-30 days, according to quantity
Price Terms FOB/ CFR/ CIF
Package Export standard package, or as per customers’ requirement





Channel Bar

Commodity 321 stainless steel channel bar
Size 5#-40#
Length 6m, or as customized
Surface Bright, pickled, black
Application Construction field, shipbuilding industry, petroleum & chemical industries, war and electricity industries, food processing and medical industry, boiler heat exchange, machinery hardware fields
Delivery Time 7-30 days, according to quantity
Price Terms FOB/ CFR/ CIF
Package Export standard package, or as per customers’ requirement
