6mm 7mm 8mm 1/2 Inch Forged 304 Stainless Steel Hollow Bar 304h Round Bar
Place of Origin | CHINA |
---|---|
Brand Name | TISCO, ZPSS, BAOSTEEL, POSCO, JISCO, LISCO, etc |
Certification | mill certificate |
Model Number | 317L stainless steel round bar |
Minimum Order Quantity | 25T |
Price | negothiable |
Packaging Details | Export Package |
Delivery Time | 15-20 days after deposit |
Payment Terms | L/C, T/T |
Supply Ability | 2000T PER MONTH OR MORE |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xMaterial | 317L Stainless Steel Round Bar | Standard | JIS, AiSi, ASTM, GB, DIN, EN |
---|---|---|---|
Type | Round Bar | Diameter | 1mm-800mm |
Length | 6-12m | Width | 20-610mm |
Technique | Hot Rolled | Surface Treatment | Polished |
Grade | 300 Series | Processing Service | Bending, Welding, Cutting |
Surface Finish | BA, BA | Application | Construction |
Steel Grade | 316, 321, 304 | ||
High Light | 6mm 304 stainless steel hollow bar,7mm 304 stainless steel hollow bar,1/2 inch 304h round bar |
317L stainless steel round bar
317L is a molybdenum bearing, low carbon content "L" grade austenitic stainless steel that provides improved corrosion resistance over 304L and 316L stainless steels. The low carbon provides resistance to sensitization during welding and other thermal processes. 317L is non-magnetic in the annealed condition but may become slightly magnetic as a result of welding.
317L stainless steel is widely used in the following applications: condensers in fossil, pulp and paper manufacturing, nuclear fueled power generation stations, chemical and petrochemical process equipment.
ElementType 317L (Wt.%)
Carbon: 0.03 max
Manganese: 2.00 max.
Phosphorus: 0.045 max.
Sulfur: 0.030 max.
Silicon: 1.00 max.
Chromium: 18.00-20.00
Nickel: 11.00-15.00
Molybdenum: 3.00-4.00
Element (Wt.%)
Carbon | Manganese | Phosphorus | Sulfur | Silicon | Chromium | Nickel | Molybdenum |
0.03max | 2.00max | 0.045max | 0.030max | 1.00max | 18.00-20.00 | 11.00-15.00 | 3.00-4.00 |
Mechanical Property
Material Item | Tensile Strength (MPa) | Yield Strength (MPa) | Extension | Hardness (HV) | Density |
317L | ≥480 | ≥176 | ≥40% | ≤200 | 7.98g/cm³ |
Surface Treatment
Surface Treatment | Definition | Application |
NO.1 | A hot - rolled piece whose surface has been treated by heat treatment, pickling or the corresponding process | Chemical Tanks, Pipes, Chemical Industry Equipment etc. |
2B | After cold rolling, heat treatment, pickling or other equivalent treatment, the final cold rolling to give appropriate luster | Medical Equipment, Food Industry, Construction Material, Kitchen Utensils etc. |
BA | After cold rolling, bright heat treatment is given | Kitchen Utensils, Electric Equipment, Building Construction etc. |
NO.4 | Products polished with abrasives 150 to 180 as specified in JIS R6001 | Kitchen Utensils, Building Construction, Medical Equipment etc. |
HL | After polishing, use the appropriate abrasive size to form a continuous polishing streak | Building Construction etc. |
8K | A mirror-like reflective surface given by polishing with finer abrasives over 800 mesh | Reflector, Mirror, Interior and exterior decoration etc. |
FAQ
Q1:What product information must I provide before making a purchase?
Q6:Do you offer a service for customized products?
