ERW ASTM Stainless Steel Welded Pipe A312 A213 TP 304L 316 316L 904L 254SMO 2205 2507
| Place of Origin | CHINA |
|---|---|
| Brand Name | TISCO, ZPSS, BAOSTEEL, POSCO, JISCO, LISCO, etc |
| Certification | mill certificate |
| Model Number | 2205 welded stainless steel pipe |
| Minimum Order Quantity | 25T |
| Price | negothiable |
| Packaging Details | Export Package |
| Delivery Time | 15-20 days after deposit |
| Payment Terms | L/C, T/T |
| Supply Ability | 2000T PER MONTH OR MORE |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | 2205 | Type | Stainless Steel Welded Pipe |
|---|---|---|---|
| Carbon | 0.03 Max | Standard | EN, BS, JIS, Etc |
| Grade | Q235, Q235B, S275, S275jr, A53, St37, Etc | Oiled Or Non-oiled | Non-oiled |
| Application | Fluid Pipe, Boiler Pipe, Drill Pipe, Hydraulic Pipe, Gas Pipe, | Technique | ERW, SAW |
| OD | 10mm 20mm | Length | 1000-5800mm,6000-12000mm |
| Processing Service | Bending, Welding, Decoiling, Punching, Cutting, Moulding | Surface Finish | 2B |
| Section Shape | Round | ||
| High Light | erw Stainless Steel Welded Pipe,astm Stainless Steel Welded Pipe,10mm ss 304 erw pipe |
||
Product Description
2205 welded stainless steel pipe
Duplex 2205 is a two-phase, ferritic, austenitic 22% chromium, 3% molybdenum, 5 to 6% nickel alloyed stainless steel. It is the most widely used duplex stainless steel grade and is characterized by high yield strength, double that of the standard austenitic stainless steel grades. It also demonstrates good fatigue strength, as well as outstanding resistance to stress corrosion cracking, crevice, pitting, erosion, and general corrosion in severe environments.
APPLICATIONS:
Chemical processing, transport and storage – pressure vessels, tanks, piping, and heat exchangers
Oil and gas exploration and processing equipment – piping, tubing, and heat exchangers
Marine and other high chloride environments
Effluent scrubbing systems
Pulp and paper industry – digesters, bleaching equipment, and stock-handling systems
Cargo tanks for ships and trucks
Food processing equipment
Biofuels plants
ElementType 2205 (Wt.%)
Carbon: 0.03 max
Manganese: 2.00 max.
Phosphorus: 0.040 max.
Sulfur: 0.030 max.
Silicon: 1.00 max.
Chromium: 21.00-24.00
Nickel: 4.50-6.50
Nitrogen: 0.08-0.20
Molybdenum: 2.50-3.50
Element (Wt.%)
| Carbon | Manganese | Phosphorus | Sulfur | Silicon | Chromium | Nickel | Nitrogen | Molybdenum |
| 0.03max | 2.00max | 0.040max | 0.030max | 1.00max | 21.00-24.00 | 4.50-6.50 | 0.08-0.20 | 2.50-3.50 |
Mechanical Property
| Material Item | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation | Hardness Rockwell C (HR C) | Hardness Brinell (HB) |
| 2205 | ≥621 | ≥448 | ≥25% | ≤31 | ≤293 |
Surface Treatment
| Surface Treatment | Definition | Application |
| NO.1 | A hot - rolled piece whose surface has been treated by heat treatment, pickling or the corresponding process | Chemical Tanks, Pipes, Chemical Industry Equipment etc. |
| 2B | After cold rolling, heat treatment, pickling or other equivalent treatment, the final cold rolling to give appropriate luster | Medical Equipment, Food Industry, Construction Material, Kitchen Utensils etc. |
| BA | After cold rolling, bright heat treatment is given | Kitchen Utensils, Electric Equipment, Building Construction etc. |
| NO.4 | Products polished with abrasives 150 to 180 as specified in JIS R6001 | Kitchen Utensils, Building Construction, Medical Equipment etc. |
| HL | After polishing, use the appropriate abrasive size to form a continuous polishing streak | Building Construction etc. |
| 8K | A mirror-like reflective surface given by polishing with finer abrasives over 800 mesh | Reflector, Mirror, Interior and exterior decoration etc. |
PIPE
| Commodity | 2205 seamless/welded stainless steel pipe |
| Grade | 2205 |
| OD | 6mm-426mm, or as customized |
| WT | 1mm-30mm, or as customized |
| Length | 5m-7m, or as customized |
| Surface | Pickling, matt, polished, mirror |
| Application | General service industries (petroleummilitary food chemicalpaper fertilizerfabricaviation and nuclear); Fluid, gas and oil transport; Pressure and heat transmission; Boilerpressure vesselheat exchanger and condenser |
| Delivery Time | 7-30 days, according to quantity |
| Price Terms | FOB/ CFR/ CIF |
| Package | In bundles, water proof packing, in wooden case, or as per customers’ requirement |
FAQ
Q1: What is your major market?
A1: 95% of our tubes export. We mainly sell to America, Canada, Australia, Japan, Russia, Germany, France, Dubai, Brazil, Chile, India, Thailand, South Africa, Egypt, Nigeria, etc.
Q2: What's the annual output?
A2: We can produce more than 21,000 tons stainless steel tubes in a year.
Q3: What is your welding method?
A3: All of our tubes are welded by TIG welding methods. Our tubes can get fully welding and smooth inner welding, without blisters, leak welding or black line. All of our tube are good for tube bending.
Q4: How do you control the quality during the polishing process?
A4: 1)As for the mirror polish square/rectangular tube, we will polish it as least four times.
2)During the polishing processing, we set a special sanding wheel to polish the welding part.
3)To avoid scratches, after polishing, the tubes will be lay out on a steel crate then we could lift the whole steel crate instead of the tube.
4)On the other hand, we use the gunny bags to protect the tube's surface when the tube laying-out.
Q5: How do you inspect the tubes?
A5: The Quality inspectors inspect the tubes during each production processes from raw material, tube welding, polishing, packaging.
1) Before the production of each machine, we will have the first checked and record the data.
2) During the production, our inspector and engineer have been carefully moniting and we record the data every two hours.
Q6: What is the MOQ?
A6: 2ton.
Q7: What’s the delivery time for the tubes normally in your company?
A7: 20-30 days for 1-4 containers base on the how many items.
Q8: What payment terms you can deal with?
A8: Mostly we deal with TT terms and L/C,for L/C we need to know which bank to open the L/C and after checking the bank information to decide whether to accpet the L/C.If you have other preference, please negotiate.
Q9: Could you print our company logo or information on the tubes plastic bag and the outside package also?Is there extra cost for it?
A9: We can follow customer’s request to print your own information plastic bag for quantity at least 1 container(22-26 tons), and we won’t charge the extra cost.
