Durable Construction Material 316 Stainless Steel Angle Iron 20mmx20mmx3mm
Place of Origin | CHINA |
---|---|
Brand Name | TISCO, ZPSS, BAOSTEEL, POSCO, JISCO, LISCO, etc |
Certification | mill certificate |
Model Number | 420 stainless steel angle bar |
Minimum Order Quantity | 25T |
Price | negothiable |
Packaging Details | Export Package |
Delivery Time | 15-20 days after deposit |
Payment Terms | L/C, T/T |
Supply Ability | 2000T PER MONTH OR MORE |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xMaterial | 420 Stainless Steel Angle Bar | Standard | JIS, AiSi, ASTM, GB, DIN, EN |
---|---|---|---|
Type | Angle Bar | Size | 20mmx20mmx3mm~150mmx150mmx12mm |
Length | 6-12m | Width | 20-610mm |
Technique | Hot Rolled | Surface Treatment | Polished |
Grade | 300 Series | Processing Service | Bending, Welding, Cutting |
Surface Finish | BA, BA | Application | Construction |
Steel Grade | 316, 321, 304 | ||
High Light | 15mm brushed steel angle,3mm 316 stainless steel angle iron,20mm 316 stainless steel angle iron |
420 stainless steel angle bar
AISI Type 420 is a martensitic stainless steel that provides increased strength and hardness relative to Type 410, with moderate corrosion resistance. It is magnetic in both the annealed and hardened conditions. Maximum corrosion resistance is attained in the fully hardened or fully hardened and stress relieved condition. High carbon content results in the formation of chromium carbide compounds, providing excellent wear resistance and edge retention when hardened. The alloy is not normally used at temperatures exceeding 800°F (427°C) due to rapid softening and loss of corrosion resistance.
APPLICATIONS
Cutlery, surgical and dental instruments, scissors, tapes, straight edges, fasteners, firearms
ElementType 420 (Wt.%)
Carbon: 0.15 max
Manganese: 1.00 max.
Phosphorus: 0.040 max.
Sulfur: 0.030 max.
Silicon: 1.00 max.
Chromium: 12.00-14.00
Nickel: 0.75 max
Element (Wt.%)
Carbon | Manganese | Phosphorus | Sulfur | Silicon | Chromium | Nickel |
0.15max | 1.00max | 0.040max | 0.030max | 1.00max | 12.00-14.00 | 0.75max |
Mechanical Property
Material Item | Tensile Strength (MPa) | Yield Strength (MPa) | Extension | Hardness (HV) | Density |
420 | ≥540 | ≥225 | ≥18% | ≤247 | 7.75g/cm³ |
Surface Treatment
Surface Treatment | Definition | Application |
NO.1 | A hot - rolled piece whose surface has been treated by heat treatment, pickling or the corresponding process | Chemical Tanks, Pipes, Chemical Industry Equipment etc. |
2B | After cold rolling, heat treatment, pickling or other equivalent treatment, the final cold rolling to give appropriate luster | Medical Equipment, Food Industry, Construction Material, Kitchen Utensils etc. |
BA | After cold rolling, bright heat treatment is given | Kitchen Utensils, Electric Equipment, Building Construction etc. |
NO.4 | Products polished with abrasives 150 to 180 as specified in JIS R6001 | Kitchen Utensils, Building Construction, Medical Equipment etc. |
HL | After polishing, use the appropriate abrasive size to form a continuous polishing streak | Building Construction etc. |
8K | A mirror-like reflective surface given by polishing with finer abrasives over 800 mesh | Reflector, Mirror, Interior and exterior decoration etc. |
Angle Bar
Commodity | 420/430 stainless steel angle bar |
Size | 20mmx20mmx3mm~150mmx150mmx12mm |
Length | 6m, or as customized |
Surface | Bright, pickled, black |
Application | Construction field, shipbuilding industry, petroleum & chemical industries, war and electricity industries, food processing and medical industry, boiler heat exchange, machinery hardware fields |
Delivery Time | 7-30 days, according to quantity |
Price Terms | FOB/ CFR/ CIF |
Package | Export standard package, or as per customers’ requirement |
