AISI ASTM A269 TP SS 310S 2205 2507 C276 201 304 304L 321 316 316L Stainless Seamless Steel Pipe Welded Tube
| Place of Origin | CHINA |
|---|---|
| Brand Name | TISCO, ZPSS, BAOSTEEL, POSCO, JISCO, LISCO, etc |
| Model Number | 201 welded stainless steel pipe |
| Minimum Order Quantity | 25T |
| Price | negothiable |
| Packaging Details | Export Package |
| Delivery Time | 15-20 days after deposit |
| Payment Terms | L/C, T/T |
| Supply Ability | 2000T PER MONTH OR MORE |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Standard | EN, BS, JIS, Etc | Grade | Q235, Q235B, S275, S275jr, A53, St37, Etc |
|---|---|---|---|
| Oiled Or Non-oiled | Non-oiled | Application | Fluid Pipe, Boiler Pipe, Drill Pipe, Hydraulic Pipe, Gas Pipe, |
| Technique | ERW, SAW | OD | 10mm 20mm |
| Length | 1000-5800mm,6000-12000mm | Processing Service | Bending, Welding, Decoiling, Punching, Cutting, Moulding |
| Surface Finish | 2B | Section Shape | Round |
| High Light | a269 ss pipe welding,2507 stainless steel welded tube,c276 stainless steel welded tubes |
||
Product Description
201 welded stainless steel pipe
201 is part of the 200 series of austenitic stainless steel. 201 is used to produce a range of household appliances, including sinks, cooking utensils, washing machines, windows, and doors. It is also used in automotive trim, decorative architecture, railway cars, trailers, and clamps. It is not recommended for structural outdoor applications because of its susceptibility to pitting and crevice corrosion.
ElementType 201 (Wt.%)
Carbon: 0.15 max
Manganese: 5.50-7.50 max.
Phosphorus: 0.06 max.
Sulfur: 0.03 max.
Silicon 1.00 max.
Chromium: 16.00-18.00
Nickel: 3.50-5.50
Nitrogen: 0.25 max.
Element (Wt.%)
| Carbon | Manganese | Phosphorus | Sulfur | Silicon | Chromium | Nickel | Nitrogen |
| 0.15max | 5.50-7.50 | 0.06max | 0.030max | 1.00max | 16.00-18.00 | 3.50-5.50 | 0.25max |
Mechanical Property
| Material Item | Tensile Strength (MPa) | Yield Strength (MPa) | Extension | Hardness (HV) | Density |
| 201 | ≥520 | ≥275 | ≥40% | <253 | 7.93g/cm³ |
Hot rolled
| Commodity | 201 hot rolled stainless steel sheet |
| Brand | TISCO, ZPSS, BAOSTEEL, POSCO, JISCO, LISCO, etc |
| Thickness | 3mm-30mm, or as customized |
| Width | 1500mm/1800mm/2000mm, or as customized |
| Length | 2000mm/2438mm/6000mm, or as customized |
| Application | automotive trim, decorative architecture, railway cars, trailers, and clamps, etc |
| Delivery Time |
Within 15 days for less than 100mt About 30 days for on and more than 100mt |
| Price Terms | FOB/ CFR/ CIF |
| Package | Standard Export Packaging |
Cold rolled
| Commodity | 201 cold rolled stainless steel sheet |
| Brand | TISCO, ZPSS, BAOSTEEL, POSCO, JISCO, LISCO, etc |
| Thickness | 0.3mm-6mm |
| Width | 1000mm/1220mm/1500mm/2000mm, or as customized |
| Length | 2000mm/2438mm/6000mm, or as customized |
| Surface | 2B/ BA/ No.4/ 8K/ HL |
| Application | automotive trim, decorative architecture, railway cars, trailers, and clamps, etc |
| Delivery Time |
Within 15 days for less than 100mt About 30 days for on and more than 100mt |
| Price Terms | FOB/ CFR/ CIF |
| Package | Standard Export Packaging |
Surface Treatment
| Surface Treatment | Definition | Application |
| NO.1 | A hot - rolled piece whose surface has been treated by heat treatment, pickling or the corresponding process | Chemical Tanks, Pipes, Chemical Industry Equipment etc. |
| 2B | After cold rolling, heat treatment, pickling or other equivalent treatment, the final cold rolling to give appropriate luster | Medical Equipment, Food Industry, Construction Material, Kitchen Utensils etc. |
| BA | After cold rolling, bright heat treatment is given | Kitchen Utensils, Electric Equipment, Building Construction etc. |
| NO.4 | Products polished with abrasives 150 to 180 as specified in JIS R6001 | Kitchen Utensils, Building Construction, Medical Equipment etc. |
| HL | After polishing, use the appropriate abrasive size to form a continuous polishing streak | Building Construction etc. |
| 8K | A mirror-like reflective surface given by polishing with finer abrasives over 800 mesh | Reflector, Mirror, Interior and exterior decoration etc. |
| Commodity | 201 seamless/welded stainless steel pipe |
| Grade | 201 |
| OD | 6mm-426mm, or as customized |
| WT | 1mm-30mm, or as customized |
| Length | 5m-7m, or as customized |
| Surface | Pickling, matt, polished, mirror |
| Application | Chemical industry, architecture, petro chemical industry, chemical fertilizer production, food industry, boiler heat exchangers, natural gas industry, pharmaceutics, warter transfer, environmental protection and construction and building area., etc |
| Delivery Time | 7-30 days, according to quantity |
| Price Terms | FOB/ CFR/ CIF |
| Package | In bundles, water proof packing, in wooden case, or as per customers’ requirement |
COIL
| Commodity | 201 hot rolled/cold rolled stainless steel coil |
| Brand | TISCO, ZPSS, BAOSTEEL, POSCO, JISCO, LISCO, etc |
| Surface | No.1/ 2B/ BA/ No.4/ 8K/ HL |
| Thickness | 0.3mm-16mm |
| Width | 1000mm-2000mm, or as customized |
| Length | as customized |
| Application | automotive trim, decorative architecture, railway cars, trailers, and clamps, etc |
| Delivery Time | Normally within 15 days, according to the quantity |
| Price Terms | FOB/ CFR/ CIF |
| Package | Standard Export Packaging |
Bar
| Commodity | 201 stainless steel round bar |
| Diameter | 1mm-800mm |
| Length | 6m, or as customized |
| Surface | Bright, pickled, black |
| Application | Construction field, shipbuilding industry, petroleum & chemical industries, war and electricity industries, food processing and medical industry, boiler heat exchange, machinery hardware fields |
| Delivery Time | 7-30 days, according to quantity |
| Price Terms | FOB/ CFR/ CIF |
| Package | Export standard package, or as per customers’ requirement |
STRIP
| Commodity | 201 stainless steel strip |
| Brand | TISCO, ZPSS, BAOSTEEL, POSCO, JISCO, LISCO, etc |
| Surface | No.1/ 2B/ BA/ No.4/ 8K/ HL |
| Thickness | 0.02mm-5mm |
| Width | 15mm-600mm |
| Length | as customized |
| Application | automotive trim, decorative architecture, railway cars, trailers, and clamps, etc |
| Delivery Time | Normally within 15 days, according to the quantity |
| Price Terms | FOB/ CFR/ CIF |
| Package | Standard Export Packaging |
SQUARE PIPE
| Commodity | seamless/welded stainless steel square pipe |
| Grade | 201 |
| Size | 10mmx10mm~200mmx200mm |
| Thickness | 1mm-10mm |
| Length | 6m, or as customized |
| Surface | Pickling, matt, polished, mirror |
| Application | Chemical industry, architecture, petro chemical industry, chemical fertilizer production, food industry, boiler heat exchangers, natural gas industry, pharmaceutics, warter transfer, environmental protection and construction and building area., etc |
| Delivery Time | 7-30 days, according to quantity |
| Price Terms | FOB/ CFR/ CIF |
| Package | Standard export packaging |
| Commodity | seamless/welded stainless steel rectangular pipe |
| Grade | 201 |
| Size | 20mmx10mm, 40mmx20mm, 50mmx20mm, 80mx60mm, 150mmx100mm, or as customized |
| Thickness | 1mm-10mm |
| Length | 6m, or as customized |
| Surface | Pickling, matt, polished, mirror |
| Application | Chemical industry, architecture, petro chemical industry, chemical fertilizer production, food industry, boiler heat exchangers, natural gas industry, pharmaceutics, warter transfer, environmental protection and construction and building area., etc |
| Delivery Time | 7-30 days, according to quantity |
| Price Terms | FOB/ CFR/ CIF |
| Package | Standard export packaging |
Angle Bar
| Commodity | 201 stainless steel angle bar |
| Size | 20mmx20mmx3mm~150mmx150mmx12mm |
| Length | 6m, or as customized |
| Surface | Bright, pickled, black |
| Application | Construction field, shipbuilding industry, petroleum & chemical industries, war and electricity industries, food processing and medical industry, boiler heat exchange, machinery hardware fields |
| Delivery Time | 7-30 days, according to quantity |
| Price Terms | FOB/ CFR/ CIF |
| Package | Export standard package, or as per customers’ requirement |
Flat Bar
| Commodity | 201 stainless steel flat bar |
| Thickness | 3mm-60mm |
| Width | 10mm-200mm, or as customized |
| Length | 6m, or as customized |
| Surface | Bright, pickled, black, polished |
| Application | Construction field, shipbuilding industry, petroleum & chemical industries, war and electricity industries, food processing and medical industry, boiler heat exchange, machinery hardware fields |
| Delivery Time | 7-30 days, according to quantity |
| Price Terms | FOB/ CFR/ CIF |
| Package | Export standard package, or as per customers’ requirement |
Channel Bar
| Commodity | 201 stainless steel channel bar |
| Size | 5#-40# |
| Length | 6m, or as customized |
| Surface | Bright, pickled, black |
| Application | Construction field, shipbuilding industry, petroleum & chemical industries, war and electricity industries, food processing and medical industry, boiler heat exchange, machinery hardware fields |
| Delivery Time | 7-30 days, according to quantity |
| Price Terms | FOB/ CFR/ CIF |
| Package | Export standard package, or as per customers’ requirement |
Square Bar
| Commodity | 201/202 stainless steel square bar |
| Size | 5mm*5mm-60mm*60mm |
| Length | 6m, or as customized |
| Surface | Bright, pickled, black |
| Application | Construction field, shipbuilding industry, petroleum & chemical industries, war and electricity industries, food processing and medical industry, boiler heat exchange, machinery hardware fields |
| Delivery Time | 7-30 days, according to quantity |
| Price Terms | FOB/ CFR/ CIF |
| Package | Export standard package, or as per customers’ requirement |
Element (Wt.%)
| C | Mn | P | S | Si | Cr | Ni | N | Mo | Ti | |
| 201 | 0.15max | 5.50-7.50 | 0.06max | 0.030max | 1.00max | 16.00-18.00 | 3.50-5.50 | 0.25max | - | - |
| 202 | 0.15max | 7.50-10.00 | 0.06max | 0.030max | 1.00max | 17.00-19.00 | 4.00-6.00 | 0.25max | - | - |
Mechanical Property
| Material Item | Tensile Strength (MPa) | Yield Strength (MPa) | Extension | Hardness (HV) | Density |
| 201 | ≥520 | ≥275 | ≥40% | <253 | 7.93g/cm³ |
| 202 | ≥520 | ≥275 | ≥40% | ≤218 | 7.98g/cm³ |
Thick Wall PIPE
| Commodity | 201 stainless steel thick wall pipe |
| Grade | 201 |
| Technique | Seamless, welded |
| OD | 20mm-426mm, or as customized |
| WT | 6mm-30mm, or as customized |
| Length | 5m-7m, or as customized |
| Surface | Pickling, matt, polished, mirror |
| Application | Chemical industry, architecture, petro chemical industry, chemical fertilizer production, food industry, boiler heat exchangers, natural gas industry, pharmaceutics, warter transfer, environmental protection and construction and building area., etc |
| Delivery Time | 7-30 days, according to quantity |
| Price Terms | FOB/ CFR/ CIF |
| Package | Standard export package, or as per customers’ requirement |
